When charging
When the Li-ion battery is being charged, the
charging status indicator lights will change de-
pending on the amount the Li-ion battery is
charged.
*: This value is also displayed by the illumination
of segments of the Li-ion battery available charge
gauge on the instrument panel.
When fully charged
All of the indicator lights
䊊
1
to
䊊
3
illuminate when
the Li-ion battery is fully charged to the selected
charging mode level.
The indicator lights turn off after approximately 5
minutes or when the charge connector is re-
moved.
When the indicator light
䊊
3
flashes
The indicator light
䊊
3
flashes when the 12-volt
battery is being charged. For additional informa-
tion, refer to “Charging the 12-volt battery” in the
“EV overview” section of this manual.
Charging CH-29
