EM-16
< PERIODIC MAINTENANCE >
[VQ40DE]
SPARK PLUG
SPARK PLUG
Exploded View INFOID:0000000008798958
Removal and Installation INFOID:0000000008798959
REMOVAL
1. Remove the ignition coil. Refer to EM-40, "Removal and Installation".
2. Remove the spark plug using a suitable tool.
CAUTION:
Do not drop or shock it.
INSPECTION AFTER REMOVAL
• Do not use a wire brush for cleaning.
• If the spark plug tip is covered with carbon, spark plug cleaner may be used.
1. Ignition coil 2. Spark plug
PBIC2901E
SEM294A
SMA773C
Revision: January 2013 2013 Xterra
