INTAKE MANIFOLD COLLECTOR
EM-27
< REMOVAL AND INSTALLATION >
[VQ40DE]
C
D
E
F
G
H
I
J
K
L
M
A
EM
N
P
O
• Tighten nuts and bolts in numerical order as shown.
Intake Manifold Collector Support
Tighten the intake manifold collector support bolts to specification in
the order as shown to install the intake manifold collector support.
Electric Throttle Control Actuator
• Tighten bolts in numerical order as shown.
• Perform the “Throttle Valve Closed Position Learning” when har-
ness connector of electric throttle control actuator is disconnected.
Refer to EC-124, "Throttle Valve Closed Position Learning"
.
• Perform the “Idle Air Volume Learning” and “Throttle Valve Closed
Position Learning” when electric throttle control actuator is
replaced. Refer to EC-125, "Idle Air Volume Learning"
.
PBIC2877E
PBIC2876E
PBIC2875E
