EM-50
< REMOVAL AND INSTALLATION >
[VQ40DE]
INTAKE VALVE TIMING CONTROL
INTAKE VALVE TIMING CONTROL
Intake Valve Timing Control Solenoid Valve (LH) INFOID:0000000008798979
REMOVAL
1. Disconnect the harness connector from intake valve timing control solenoid valve (LH).
2. Remove intake valve timing control solenoid valve bolts (LH) and O-ring from rocker cover.
CAUTION:
Do not reuse O-ring.
INSTALLATION
Installation is in the reverse order of removal. Refer to EM-51, "Exploded View".
CAUTION:
• Do not reuse O-rings.
• Lubricate the new O-ring for the intake valve timing control solenoid valve with clean engine oil
before installing.
Intake Valve Timing Control Solenoid Valve (RH) INFOID:0000000008798980
REMOVAL
1. Remove intake manifold collector. Refer to EM-25, "Removal and Installation".
2. Disconnect the harness connector from intake valve timing control solenoid valve (RH).
3. Remove intake valve timing control solenoid valve bolts (RH) and O-ring from rocker cover.
CAUTION:
Do not reuse O-ring.
INSTALLATION
Installation is in the reverse order of removal. Refer to EM-51, "Exploded View".
CAUTION:
• Do not reuse O-rings.
• Lubricate the new O-ring for the intake valve timing control solenoid valve with clean engine oil
before installing.
