SSI0770
1. Meters and gauges (P.2-4)
2. Center ventilator (P.4-13)
3. Audio system* or Navigation system** (P.4-21)
— Clock* (P.2-40)
4. Hazard warning flasher switch (P.2-37)
5. Integrated Control System*
— Clock (P.2-21)
— Drive mode (P.5-22)
— Heater and air conditioner control (P.4-14)
— Defroster switch (P.2-33)
5. Heater and air conditioner control (models without
Integrated Control System) (P.4-14)
— Defroster switch (P.2-33)
6. Front passenger supplemental air bag (P.1-35)
7. Side ventilator (P.4-13)
8. Fuel-filler door release handle (P.3-23)
9. Hood release handle (P.3-21)
10. Push-button ignitio n switch (models with Intelli-
gent Key system) (P.5-11)
11. AUX/USB connector* (P.4-25)
12. Parking brake (P.5-26)
13. Cup holder (P.2-41)
14. Power outlet (P.2-41)
15. Glove box (P.2-43)
*: if so equipped
**: Refer to the separate Navigation System Owner’s
Manual.
INSTRUMENT PANEL
Illustrated table of contents 0-7
