10
LI-ION BATTERY CHARGING
Before charging the Li-ion battery, see your Owner’s Manual for detailed warnings
and cautions when charging your battery.
There are three methods available to perform the charge operation:
normal charge, trickle charge and quick charge (if so equipped).
NORMAL CHARGE
Perform a normal charge using the charger installed in your home.
It takes approximately 5.5-9.5 hours for the 30 kW/h Li-ion battery
(if so equipped) to charge from empty to full with a 6.6 kW charger
(if so equipped).
To charge your vehicle:
• Place the power switch in the OFF position.
• Push the charge port lid opener switch located on the instrument panel to the
left of the steering wheel.
• Press the charge port tab and open the cap.
• Connect the charge connector
1
to the
charge port
2
. When connected correctly,
a beep will sound once.
To stop charging:
• Press the button
3
on the charge
connector to release the lock and remove
the charge connector from the
charge port.
• Close the charge port cap and the charge port lid.
TRICKLE CHARGE
Perform a trickle charge by connecting the Electric Vehicle Supply Equipment
(EVSE) (if so equipped) to a dedicated 110-120V, 15A power outlet.
It takes approximately 26 hours to charge the 30 kW/h Li-ion battery
(if so equipped) from discharged to charged.
To charge your vehicle:
• Place the power switch in the OFF position.
• Push the charge port lid opener switch
located on the instrument panel to the left
of the steering wheel.
• Press the charge port tab and open the cap.
• Connect the EVSE plug
4
to a dedicated
110-120V, 15A power outlet. The EVSE control
box’s green indicator light
5
will illuminate.
• Remove the safety cap from the
charge connector.
4
6
8
5
1
2
3
ESSENTIAL INFORMATION
