SRS Air Bag System Components Location
Avoid cutting air bag system parts. However, the vehicle can be cut (except inflators) under the following
conditions:
• The front, side and curtain air bags have deployed.
• At least three (3) minutes have passed after the 12V battery negative (-) cable has been
disconnected and the high voltage system has been shut down.
= Inflators (Peel back plastic trim parts prior to cutting
operations to confirm exact inflator location.)
= Sensors
AAYIA0034GB
27
