1. Crash zone sensor 2. Supplemental front-impact air
bag modules
3. Front seat-mounted side-impact
supplemental air bag modules
4. Roof-mounted curtain side-
impact supplemental air bag
inflators
5. Roof-mounted curtain side-
impact supplemental air bag
modules
6. Front door satellite sensors
7. Lap outer pretensioner (driver
side only)
8. Seat belt with pretensioner 9. Rear satellite sensors (located
in lower B-pillar)
10. Air bag control unit (ACU)
1
1 2 3 4 5
6 7
8 9 10
AAYIA0095ZZ
