[ Edit: 2016/ 11/ 24 Model: E12-A ]
2-18 Instruments and controls
Parking brake reminder chime
E12-A-120227-B80A3D8C-224E-48DA-A89C-D15FFA961236
The parking brake reminder chime will sound if the
vehicle is driven at more than 7 km/h (4 MPH) with the
parking brake applied. Stop the vehicle and release the
parking brake.
Seat belt warning chime (if equipped)
GUID-CBB217A2-E180-471B-960C-B4E9ECA3D6DC
When the vehicle speed exceeds 15 km/h (9 MPH),
the chime will sound unless the driver’s seat belt is
securely fastened. The chime will continue to sound for
about 90 seconds until the seat belt is fastened.
Idling Stop System reminder buzzer
E12-A-120227-61FF4939-1265-434D-9B5F-81EA5059E1C8
The Idling Stop System reminder buzzer will sound if
the engine hood is opened while the Idling Stop
System is activated.
Be sure to check if the engine hood is open. When the
engine hood is opened the engine will be in the normal
stopped state. In this case, restart the engine with the
ignition switch.
E12-A-120227-6CE214B9-19DE-4159-84D8-2460178800A4
HEADLIGHT SWITCH
E12-A-120227-2E6B824B-C09F-4F4C-A942-556DF911636C
SIC3783
NISSAN recommends that you consult the local
regulations concerning the use of lights.
AUTO position (if equipped)
GUID-18F93F07-C0E5-49D3-8400-F8289D4AE07E
When the ignition switch is in the “ON” position and
the headlight switch is in the “AUTO” position, the
headlights, front clearance lights, instrument panel
lights, rear combination light, and other lights turn on
automatically depending on the brightness of the
surroundings.
The headlights will turn on automatically at twilight or in
rainy weather (when the windshield wiper is operated
continuously).
When the ignition switch is placed in the “OFF”
position, the lights will turn off automatically.
JVH0234X
Example
CAUTION:
Do not place any objects on top of the sensor *
A
. The sensor senses the brightness level and
controls the autolight function. If the sensor is
covered, it reacts as if it is dark, and the
headlights will illuminate.
position
E12-A-120227-7647D991-88A6-4CB7-AA85-C2350DF02974
The position turns on the front clearance lights,
instrument panel lights, rear combination lights and
other lights.
position
E12-A-120227-15242FF5-B58E-467A-A6D4-12842D922048
The position turns on the headlights in addition to
the other lights.
HEADLIGHT AND TURN SIGNAL
SWITCH
Condition:
