[ Edit: 2012/ 4/ 9 Model: E26-A ]
1. Front map light
2. Room light
3. Front fog light (if equipped)
4. Headlight
5. Clearance light
6. Front turn signal light
7. High-mounted stop light
8. Luggage room light
9. License plate light
10. Rear combination light
Replacement procedures
GUID-C55D2469-57EF-4BD0-8476-6D195D02B8DD
SDI1805
:
REMOVE
:
INSTALL
All other lights are either type A, B, C or D. When
replacing a bulb, first remove the lens and/or cover.
JVM0149X
Front turn signal light
JVM0150X
Clearance light
JVM0127X
Rear combination light
*
1
: Stop/tail light
*
2
: Turn signal light
*
3
: Reverse light
Maintenance and do-it-yourself 8-27
