[ Edit: 2012/ 4/ 9 Model: E26-A ]
CHECKING BULBS
GUID-494FB3B3-70EC-412A-8322-911C910D5FD5
With all doors closed, apply the parking brake, fasten
the seat belts and turn the ignition switch to the “ON”
position without starting the engine. The following
lights will illuminate:
, , ,
If equipped, the following lights will illuminate briefly
and then turn off:
, , , ,
If any lights fail to illuminate, it may indicate a burned-
out bulb or an open circuit in the electrical system.
Have the system checked, and if necessary repaired,
by a NISSAN dealer promptly.
WARNING LIGHTS
GUID-CBC0E608-E05A-481E-BE9D-C21FE123A93A
Anti-lock Braking System (ABS)
warning light (if equipped)
GUID-FF26EA6A-9AC2-438C-9C00-35F3B3AFA308
When the ignition switch is in the “ON” position, the
Anti-lock Braking System (ABS) warning light illumi-
nates and then turns off. This indicates the ABS is
operational.
If the ABS warning light illuminates while the engine is
running, or while driving, it may indicate the ABS is not
functioning properly. Have the system checked by a
NISSAN dealer.
If an ABS malfunction occurs, the anti-lock function is
turned off. The brake system then operates normally,
but without anti-lock assistance. (See “Brake system”
(P.5-15).)
Brake warning light
GUID-93522551-B7F5-409C-9CCF-4871BB4CD273
WARNING:
. If the brake fluid level is below the minimum
mark on the brake fluid reservoir, do not
drive the vehicle until the brake system has
been checked by a NISSAN dealer.
. Even if you judge it to be safe, have your
vehicle towed because driving it could be
dangerous.
. Depressing the brake pedal without the
engine running and/or with a low brake
fluid level could increase the stopping dis-
tance and require greater pedal travel dis-
tance and effort.
The brake warning light indicates the parking brake
system operation and a low brake fluid level of the
brake system.
Parking brake warning indicator:
GUID-896AA31A-81D 0-4E9B-81ED-1F58D53AA854
When the ignition switch is in the “ON” position, and
the parking brake is applied, the brake warning light
illuminates. When the parking brake is released while
the engine is running, the brake warning light turns off.
If the parking brake is not fully released, the brake
warning light remains on. Be sure that the brake
warning light has turned off before driving. (See
“Parking brake” (P.3-11).)
Low brake fluid warning indicator:
GUID-896AA31A-81D 0-4E9B-81ED-1F58D53AA854
If the brake warning light illuminates while the engine is
running, or while driving, and the parking brake is
released, it may indicate the brake fluid level is low.
When the brake warning light illuminates while driving,
stop the vehicle safely as soon as possible. Stop the
engine and check the brake fluid level. If the brake fluid
level is at the minimum mark, add brake fluid as
necessary. (See “Brake and clutch fluid” (P.8-15).)
If the brake fluid level is sufficient, have the brake
system checked by a NISSAN dealer promptly.
Charge warning light
GUID-8416D213-E27 0-49FB-9110-7F164D1BF337
When the ignition switch is in the “ON” position, the
charge warning light illuminates. After starting the
engine, the charge warning light turns off. This
indicates the charging system is operational.
If the charge warning light illuminates while the engine
is running, or while driving, it may indicate the charging
system is not functioning properly and may need
servicing.
When the charge warning light illuminates while
driving, stop the vehicle safely as soon as possible.
Stop the engine and check the alternator belt. If the
alternator belt is loose, broken or missing, the charging
system needs repair. (See “Drive belts” (P.8-13).)
If the alternator belt appears to be functioning correctly
but the charge warning light remains illuminated, have
the charging system checked by a NISSAN dealer
promptly.
CAUTION:
Do not continue driving if the alternator belt is
loose, broken or missing.
Instruments and controls 2-11
