[ Edit: 2012/ 4/ 9 Model: E26-A ]
position
GUID-4DB0C7F6-938D-479B-8592-5B61D4A1F163
The position turns on the headlights in addition to
the other lights.
Headlight beam
GUID-DA59C96E-5B1D-4867-89A4-0391BAA4A640
JVI0371X
Type A
JVI0344X
Type B
To turn on the high beam, push the lever towards the
front position
*
1
.
To turn off the high beam, return the lever to the neutral
position
*
2
.
To flash the headlights, pull the lever towards the
rearmost position
*
3
. The headlights can be flashed
even when the headlights are not on.
Battery saver system
GUID-405CBAFE-3453-4FB5-88EC-23DC32C599A1
The light reminder chime will sound if the driver’s door
is opened while the following improper operations are
found:
. The headlight switch is in either the
or
position, and the ignition switch in the “ACC”,
“OFF” or “LOCK” position.
Be sure to turn the headlight switch to the “OFF”
position when you leave the vehicle.
CAUTION:
Do not leave the lights on when the engine is not
running for extended periods of time to prevent
the battery from being discharged.
HEADLIGHT AIMING CONTROL (if
equipped)
GUID-534109AC-6D02-4975-8686-5A4EA96AD0E8
SIC2275
The headlight aiming control operates when the
ignition switch is in the “ON” position and the headlight
is on to allow the headlight axis to be adjusted
according to the driving condition.
When driving with no heavy load/luggage or driving on
a flat road, select the normal position “0”.
If the number of occupants and load/luggage in the
vehicle changes, the headlight axis may become higher
than normal.
If the vehicle is traveling on a hilly road, the headlights
may directly shine on the rearview and outside mirrors
of a vehicle ahead or the windshield of an oncoming
vehicle, which may obscure other drivers’ vision.
To adjust to the proper aiming height, turn the switch
accordingly. The higher the number, designated on the
switch, the lower the headlight axis.
Select the switch position by referring to the following
samples.
Instruments and controls 2-15
