SE-24
< SERVICE INFORMATION >
REAR SEAT
1. Install the rear seatback side bracket, temporarily tighten the
seatback assembly and rear seatback side bracket bolt.
2. Lift to fold up seatback assembly. Be sure to lock seatback
assembly to rear seat striker.
3. Tighten the rear seatback side bracket bolt.
NOTE:
Confirm that side hinge bracket location pin is set to the hole on
the seatback backside.
• Install the left rear seat back brackets and seatback bolts.
• Install the right rear seat back brackets and the rear seat back
bracket bolts.
Disassembly and Assembly INFOID:0000000007330252
60:40 SPLIT FOLD DOWN SEAT - HATCHBACK
Disassembly of Armrest
1. Fold up the backside of the seatback trim and then remove the
armrest nuts.
PIIB2484J
WIIA1288E
WIIA1287E
PIIB2913J
