Wiegand 1. Input: provided with the
use of external card reader
2. Output
2.1 Access Controller
mode: Facility Code
and ID
2.2 Reader mode:
Values read from Card
reader
※4 characters only for ID
Size
Case 90 (W)* 200 (L)* 48 (H) mm
Door support Dead Bolt / Strike / EM Lock / auto door
Adapter 1
In: AC 100V ~ 240V, 50/60 Hz
Out: DC 12V, 3A (24V OK)
Power
Adapter 2
In: AC 100V ~ 240V, 50/60 Hz
Out: DC 5V, 3A
Guidelines recorded in voice
Downloadable logo/firmware
ID length (4 ~ 15 digits)
Additional
Function
Authentication results to be displayed in
LED
Network Board
Door Control Board
Optional
RF Module
(125KHz HID, 13.56MHz Mifare)
Temperature
Storage -25℃ ~ 65℃
