DIA Functions
To change code (Function #0)
To activate users (Function #1)
To disable/enable users (Function #2)
To delete user (Function #3)
Lock/Keypad functional test (Function #5)
Lock audit function (Function #7)
Set time delay parameters (Function #9)
For Complete DIA Instructions, please refer to DIA Board Technical Reference Manual
GENERAL
The EM35-50 features a 6-digit Manager code and up to 9 user codes. A double beep follows
entry of a valid code. A long beep follows entry of an invalid code. If 10 seconds elapse without
a key press, the code entry will be cancelled.
OPENING
Enter code (factory code =
5-5-5-5-5-5
), double beep = valid entry
Rotate keypad or knob CW to retract lock bolt
If not opened within 3 seconds, the lock re-secures automatically
Turn boltwork handle to OPEN position
If the first code entry fails, wait 10 seconds before re-entering
Locking / Status:
Turn boltwork handle to the LOCKED position
Rotate keypad or knob CCW to extend lock bolt
Verify locked/secure status by attempting to rotate handle
Manipulation Protection:
Upon entry of four consecutive invalid codes, the keypad is blocked and will not accept entries for 5 minutes. During this
period, the LED flashes every 10 seconds and any key press causes a long beep. Upon expiration, the entry of two more
invalid codes restarts the 5 minute blocking period.
Best Practices
Change the factory code before you begin using the safe! Securely store all codes.
Do not use personal data (i.e. birthdays, telephone numbers, etc.) as a code.
LOW BATTERY INDICATION
NOTE: A series of beeps following code entry indicates a weak battery that must be replaced
Use ONLY Energizer™ or Duracell™ 9V ALKALINE batteries
Straight Bolt EM35•50 OPERATION • Rev. 2402A MT • © 2024 QSecurity Industries
QSecurityProducts.com • 1014 S. Main Street • Nicholasville, Kentucky 40356 • 859.241.2063
To view our full line,
product updates,
instruction manuals
and warranty
Straight Bolt
EM35•50 Operation - DIA Board
