STEP 1
•
Take the N2 controller box from the installation shelf and put it aside.
• Separate the installing shelf and controlling box shelf. Remove the two central beams inside.
STEP 2
•
Use four M6x10 hexagon flat round head screws (part #15) to fix the frame and standing pole. Repeat for opposite side. (total of 8 pcs)
• Use two M6x14 hexagon flat round head screws (part #16) to fix the side panel and frame. Repeat for opposite side. (total of 4 pcs)
M6x10 screws (part #15)
4 pcs
M6x14 screws (part #16)
2 pcs
