Noaton VEGA - Parameters; Installation

EN
27
2 Parameters
Model
VEGA
Nominal voltage and frequency
220-240 V ~ AC 50/60 Hz
Max. engine input power (W)
26 W
Lighting input power
2x20 W
Luminous flux
100 lm / W
Light colours
Warm white / daylight white / cool white
(3000K/4000K/6000K)
Bluetooth speaker
Yes (power 3-5 W)
Colour rendering index (Ra)
>85
Protection class
Class II
Number of blades / material
5 / ABS
Dimmable
Yes
Maximum slope of the ceiling
90° (can be installed on a wall)
Remote control
Yes (IR)
Fan dimensions (width x height)
56 x 22 cm
Weight
2.6 kg
Model 11056 (Ø 56 cm)
Speed
1
2
3
Input power (W)
16
21
26
Rotations per minute
700
900
1100
Airflow (m
3
/min)
35
40
45
Noise level (dB)
20
25
30
3 Installation
1) Mount the supplied mounting bracket to a suitable place on the ceiling or wall using the supplied
dowels and screws.
2) Disconnect the household power supply. This will prevent the risk of electric shock.
3) Connect the conductor from the home circuit to the corresponding conductors coming out of the
fan.
4) Fix the fan body to the mounted bracket with the screws. Make sure that the conductors are not
pinched in any way.
5) Check that the screws are properly tightened.
6) Restore the power supply.
7) The fan is ready for use.
