Noblewell NWCT1B - CAM LOCK SYSTEM OPERATION

- 2 -
1. Screw the cam bolt [C] into the threaded insert on the panel.
2. Connect both panels together making sure cam bolt [C] goes into the
pre-drilled large hole on the end of panel for cam lock [D].
3. Insert the cam lock [D] into the pre-drilled large hole on the panel. Make
sure the cross slot of cam lock [D] faces out.
4. Rotate the cam lock [D] clockwise with a self-supplied phillips screwdriver
to lock the cam bolt [C] in place.
C
D
C C C
Tools Needed (Not lncluded)
CAM LOCK SYSTEM OPERATION
Phillips Screwdriver Rubber Mallet
C
C
D
D
