Designation of Parts and Operating Elements
Shutter speed setting knob (2) Double exposue button (6)
shutter release
Connection for PANOLUX 150 (12) button (4)
Lug for camera LED indicator(6) start button (5b) lug for camera
stap (8) strap (8)
ON/OFF switch (10) accessory shoe for PANOLUX 150 (13) film advance knob (5)
Battery deep of field start
compartment scale (25a) button (5b)
cover (24)
Counter (5a)
Tripod bushing Connetion for slow
exposure modul (5a)
MODEL 150
MODEL 175
Above:View of above
Below on left:View of behind
Below on right:View of below
