1508(RM-338)
Disassembly/Assembly Nokia Customer Care
Issue 1
Copyright © 2008 Nokia, All rights reserved
Disassembly Instruction
1 2
Depress battery latch and remove battery cover. Using the SRT-6 start at the bottom of the phone and
work around the ed
es to loosen the A-Cover.
3
4
-
5 6
Remove the earpiece speaker by lifting with dental tool. Remove 6 ea. #5+ TORX screws.
