1508(RM-338)
Disassembly/Assembly Nokia Customer Care
Issue 1
Copyright © 2008 Nokia, All rights reserved
7
8
Remove LCD frame. Separate the engine module and B-Cover
9
10
Lift and remove the antenna assy using the SS-93. Lift and remove the IHF speaker using the SS-93.
11
12
Push out and remove Mylar film. Using SS-93 carefully lift LCD.
