Nokia 1616 User Giude

Get started
Insert the SIM card and battery
This phone is intended for use with the BL-5CB battery.
Safe removal. Always switch the device off and disconnect the charger before removing
the battery.
1 Place your finger in the recess at the bottom of the device, and carefully lift and
open the back cover (1).
2 Lift the battery, and remove it (2).
3 Insert the SIM card (3). Ensure the contact surface area is facing down and the
beveled corner of the SIM card is facing the bottom of the device.
4 Replace the battery (4) and back cover (5, 6, 7).
Remove the SIM card
Press the release spring (1), and slide out the SIM card (2).
Charge the battery
Your battery has been partially charged at the factory. If the device indicates a low
charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
4Get started

Nokia 1616 Specifications

General

Display type	TFT
Display diagonal	1.8 \
Display resolution	128 x 160 pixels
Display number of colors	65536 colors
Internal memory	- MB
Networking type	EGSM/GSM
Operating frequency	1900/1800/900/850 MHz
FM radio	Yes
Ringer type	Polyphonic
Audio formats supported	mp3
Polyphonic rings quantity	32
Product color	Black
Battery type	BL-5CB
Talk time (2G)	8.52 h
Battery capacity	800 mAh
Standby time (2G)	540 h
SIM card capability	Single SIM
Form factor	Bar
Phonebook capacity	500 entries
Personal info management (PIM)	Alarm clock, Calendar
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network

Weight and Dimensions

Depth	107.1 mm
Width	45 mm
Height	15 mm
Weight	78.55 g
