Technical Specifications
17
8. Technical Specifications
Power supply ACW-3
Environmental specifications
External antenna specifications
Electro-magnetic compatibility (Europe)
Dimensions 182 x 101 x 46 mm withouth dual-band
antenna
Weight 420 g
Charger type Switched mode power supply
AC mains plug type Europe, UK, US
Input voltage 100-240 VAC
DC connector 5.5. mm DC plug
Weight 75 g + cables
Volume 115 cm3
Cable length AC 1500 mm, DC 1500 mm
Operating conditions 0C...+55C
Storage conditions -40C...+70C
Relative humidity range under normal operating conditions
20...75%. The terminal is not protected against ingress of water or
liquids of any type.
Operating frequency
range
890 - 960 MHz and 1710 - 1880 MHz
Antenna gain Over 5 dBm
Nominal antenna
cable impedance
50 Ohm
Antenna cable
connector
Standard FME connector
The GSM terminal is tested for electro-magnetic compatibility
(EMC) according to the ETS 300 342-1/13/standards.
53068en_1.fm Page 17 Tuesday, March 20, 2001 2:30 PM
