Nokia 3410 Manual

CONFIDENTIAL 7 (44)
NHM—2/5/6 Repairhints
Customer Care Europe, Middle East & Africa 3410 Version 4.0 Approved
SCCE Training Group Date 20.11.2002
© NMP 2002
Checked by:
Customer Care E&A
Approved by:
SCCE Training Group
IMPORTANT INFORMATION
Changing of EEPROM D301
If it is necessary to change D301, take a look at chapter 2 on page 14 “Changing of D301” how to proceed.
Furthermore never change D301 if you have no permission to rewrite IMEI – otherwise all phone data will be lost!
To avoid further problems send the phone to a higher-level NOKIA Service Center.
Changing of COBBA N800
If it is necessary to change COBBA, you have to rewrite IMEI & SIMlock data and flash the phone!
Also RX/TX-values must be realigned.
Changing of CCONT N700
If it is necessary to change CCONT, you have to realign A/D values.
Changing components in RF-part
If it is necessary to change any main component in RF-part (IC´s, oscillators, filters…) you have to realign all RX/TX values.
In case of problems to tune RF-values of GSM1800 band, check in WinTesla Configure/Options if automatic rescan function
is activated for the phone. If selected, the band will change to GSM1800 but due to the rescan the phone changes back to
GSM900. To solve the problem deactivate the automatic rescan function if necessary.

Nokia 3410 Specifications

General

Weight	114 g (4.02 oz)
Network Technology	GSM
2G bands	GSM 900 / 1800
GPRS	No
EDGE	No
Status	Discontinued
SIM	Mini-SIM
Memory Card slot	No
Phonebook	Yes
Call records	10 dialed, 10 received, 10 missed calls
Camera	No
Alert types	Vibration; Downloadable monophonic ringtones
Loudspeaker	No
3.5mm jack	No
Messaging	SMS
Clock	Yes
Alarm	Yes
Java	No
Predictive text input	Yes
SMS to many	Yes
Calculator	Yes
Stopwatch	Yes
Xpress-on covers	Yes
WAP	No
Vibrating alert	Yes
Ringtones	Monophonic
FM radio	No
Bluetooth	No
Infrared port	No
USB	No
Display	Monochrome graphic
Battery	Removable Li-Ion battery
Stand-by time	Up to 260 h
Released	2002
Announced	2002
Games	Snake II, Space Impact, Bantumi
