13 Volume keys
14 Loudspeaker
15 Hidden display
16 Charger connector
17 Micro USB cable connector
18 Wrist strap eyelet
Insert the SIM card and battery
Note: Switch off the power and
disconnect the charger and any other
device before removing the covers.
Avoid touching electronic components
while changing the covers. Always store
and use the device with the covers
attached.
The SIM card and its contacts can be
easily damaged by scratches or
bending, so be careful when handling,
inserting, or removing the card.
1 Open the back cover, and remove it.
2 Remove the battery.
3 Open the SIM card holder. Insert the
SIM card into the holder with the
bevelled corner facing down and
the contact surface area facing
toward the contacts of the device.
The side with the bevelled corner
fits below the rim of the device.
Close the SIM card holder.
6Get started
www.nokia.com/support
