10.2 Signal strength LEDs
10.1 Status LED
All models of the Nokia FastMile 4G Receiver have a status LED:
• Figure 16 shows the location of the status LED on the Compact mono-band and
ABA models of the Nokia FastMile 4G Receiver
• Figure 17 shows the location of the status LED on the Compact multi-band models
of the Nokia FastMile 4G Receiver
Figure 16 Location of the status LED on the Compact mono-band and ABA models of the Nokia
FastMile 4G Receiver
28799
Figure 17 Location of the status LED on the Compact multi-band
models of the Nokia FastMile 4G Receiver
28772
The status LED behaves differently depending on whether the Nokia FastMile 4G
Receiver is managed from:
• the Nokia Altiplano FastMile Controller (through NETCONF): see Table 9 •
an ACS (through TR-069): see Table 10
LEDs
Table 9 Status LED behavior for Nokia FastMile 4G Receiver managed
from the Nokia Altiplano FastMile Controller
LED color
LED priority
LED behavior
Status information
Status
LED
Status LED
