Nokia 6510 Support Guide

1/4
1. INTRODUCTION
How to configure Pocket PC device to function with Nokia 6510 phone as a modem with it
•
Pocket PC device and Nokia 6510 phone are the basic requirements
•
Data services (at least outgoing data) should be activated in order to be able to make
data calls
•
Good GSM coverage and a well-charged battery in both devices as the data connection's
power consumption is usually quite high.
•
When you wish to use GPRS connection please verify from your operator that GPRS is
activated on your SIM card and your SIM card supports GPRS
•
When you are roaming in other GSM operator's network please verify that they have also
GPRS roaming agreement
2. SETTING UP A NEW CONNECTION
1. Go to the Start menu and select Settings
2. Select Modem
3. You should now have a list of available connections; just click on the New Connection…
option.
4. Complete the settings as shown in the figures below:
Figure 1. Select a modem and Figure 2. Check Connection Figure 3. Type in the ISP's phone
check the Baud Rate (When using preferences. Especially that number (typically in GPRS
HSCSD it recommended to use the Flow Control selected is HW. Connection the ph. number is *99#,
I e 57400). After that tap Tap OK on upper right please check from your GSM
Advanced… corner and then tap Next operator) and then tap Next.

Nokia 6510 Specifications

General

Network	GSM 900 / 1800
Display Type	Monochrome graphic
Phonebook	500 entries
Call Records	10 dialed, 10 received, 10 missed calls
Battery Type	Removable Li-Ion 830 mAh battery (BLB-2)
Battery Capacity	830 mAh
Stand-by	Up to 300 h
SIM	Mini-SIM
EDGE	No
Announced	2002, Q1
Status	Discontinued
Memory Card slot	No
Alert types	Vibration; Downloadable monophonic ringtones
Loudspeaker	No
3.5mm jack	No
Messaging	SMS
Radio	No
Clock	Yes
Alarm	Yes
Java	No
Predictive text input	Yes
SMS to many	Yes
Calculator	Yes
Stopwatch	Yes
Infrared port	Yes
Dimensions	97 x 43 x 20 mm
GPRS	Class 4
Games	Snake II, Space Impact
Weight	84 g
