CCS Technical Documentation Troubleshooting Instructions
Company confidential NHL-4/4U
,VVXH 1RNLD&RUSRUDWLRQ 3DJH
)LJXUH3$DQG$QWHQQD6ZLWFKWURXEOHVKRRWLQJ
PA & ant switch
troubleshooting
Yes
Check with RF probe
signal level on
PA input >=0dBm (*
OK ?
Yes
Replace
ant. switch
Yes
*(When 1kOhm passive probe is used,
correct the measurement by +26dB
Check with
oscilloscope:
-VANT_1 (GSM900)
-VANT_2 (GSM1800)
-VANT_3 (GSM1900)
OK ?
Check with
oscilloscope:
-VBATT ~4V
- VTXB = 2.8 V pulsed
- VTxLO_GSM = 0V (GSM900)
OK ?
Check
VANT lline components
OK ?
Replace
PA
Replace
HELGA
Replace
faulty
component(s)
Check components
around PA
OK ?
Replace
faulty
component(s)
Yes
Yes
Yes
No
No
No
No
