Nokia 6790 Surge / Nokia 6790 Slide / Nokia 6760 Slide
RM-492 / RM-599 / RM-573
Service Manual Level 1&2
15
Confidential
Copyright © 2009 NOKIA
All rights reserved
Version 1.0
ISSUE 1
19) After removing the first lid remove also the
three remaining lids.
20) Unscrew these two Phillips size 00 screws in the
order shown. Do not use them again.
21) Move the slide to the opposite position. 22) Use the dental tool to lift and remove the RIGHT
and the LEFT SCREW CAP DECO COVERS. They cannot
be used again.
23) Unscrew these two Phillips size 00 screws in the
order shown. Do not use them again.
24) Use SRT-6 to release the clips holding the A-
COVER ASSEMBLY.
To Next Page
