8 Headset connector/Nokia AV
Connector (2.5 mm)
9 Charger connector
10 Camera key
11 Release button
12 Strap eyelet
13 Camera lens
14 Loudspeaker
15 Microphone
Note: Avoid touching this connector as it is
intended for use by authorised service personnel only.
Switch the phone on and off
To switch the phone on or off, press and hold the power
key.
© 2008 Nokia. All rights reserved. 19
