Interface Configuration
7210 SAS M, T, X, R6, R12, Mxp, S, Sx Interface Configuration Guide Page 115
Packet length=1500 (Length of IP packet) +14 (L2 header) +4 (length of SAP tag) =1518.
The packet is dropped as packet length is greater than the service MTU configured.
Note: Please check the 7210 platform release notes for other restrictions with regards to MTU
checking and processing on each of the platforms.
Deploying Pre-provisioned Components for 7210 SAS-M, 7210
SAS-X, 7210 SAS-T, 7210 SAS-Mxp, 7210 SAS-Sx/S 1/10GE, and
7210 SAS-Sx 10/100GE.
Appropriate MDAs are auto-provisioned in 7210 SAS-M, 7210 SAS-X, 7210 SAS-T, 7210 SAS-
Mxp, 7210 SAS-Sx/S 1/10GE and 7210 SAS-Sx 10/100GE devices. User is not required to
provisions the slots or MDA on these platforms.
Deploying Pre-provisioned Components for 7210 SAS-R6 and
7210 SAS-R12
When a line card/MDA is installed in a pre-provisioned slot, the device detects discrepancies
between the pre-provisioned card and MDA type configurations and the types actually installed.
Error messages display if there are inconsistencies and the card will not initialize.
When the proper pre-provisioned card are installed into the appropriate chassis slot, alarm, status,
and performance details will display.
The 7210 SAS-R6 devices has 6 IMM slots and 2 SF/CPM slots which are not auto-provisioned
and needs to be provisioned by the user.
The 7210 SAS-R12 devices has 12 IMM slots and 2 SF/CPM slots which are not auto-provisioned
and needs to be provisioned by the user.
NOTE: 7210 SAS-R6 does not support a mix of imm-sas-r (IMMv1) and imm-sas-r-b (IMMv2)
cards in the same chassis. In other words, user can either have all cards in the chassis to be of type
