Interface Configuration
7210 SAS M, T, X, R6, R12, Mxp, S, Sx Interface Configuration Guide Page 203
LLDP Ethernet Port Commands
lldp
Syntax lldp
Context config>port>ethernet
Description Platforms Supported: 7210 SAS-M, 7210 SAS-X, 7210 SAS-Mxp, 7210 SAS-Sx/S 1/10GE,7210 SAS-Sx
10/100GE, 7210 SAS-R6, 7210 SAS-R12, 7210 SAS-T.
This command enables the context to configure Link Layer Discovery Protocol (LLDP) parameters on the
specified port.
tunnel-nearest-bridge-dest-mac
Syntax [no] tunnel-nearest-bridge-dest-mac
Context config>port>ethernet>lldp
Description Platforms Supported: 7210 SAS-M, 7210 SAS-X, 7210 SAS-Mxp, 7210 SAS-Sx/S 1/10GE,7210 SAS-Sx
10/100GE, 7210 SAS-R6, 7210 SAS-R12, 7210 SAS-T.
This command allows user to configure tunneling for LLDP frames that use the nearest-bridge-dest-mac as
destination MAC address. If enabled using the command tunnel-nearest-bridge-dest-mac, all frames
received with the appropriate destination mac address are forwarded transparently to the remote end of the
service. To forward these frames transparently the port on which tunneling is enabled must be configured
with NULL SAP and the NULL SAP must be configured in an Epipe service. Tunneling is not supported for
any other port encapsulation or when using any other service.
Additionally, before enabling tunneling, admin status for LLDP dest-mac nearest-bridge must be set to
disabled or Tx only, using the command admin-status available under configure> port> ethernet> lldp> dest-
mac nearest-bridge. If admin-status for dest-mac nearest-bridge is set to receive and process nearest-bridge
LLDPDUs (that is, if either rx or tx-rx is set) then it overrides the tunnel-nearest-bridge-dest-mac command.
The following table lists the behavior for LLDP with different values set in use for admin-status and when
tunneling is enabled or disabled:
Nearest-bridge mac
Admin status
Tunneling
Enabled
Tunneling
Disabled
Rx Process/Peer Process/Peer
Tx Tunnel Drop
Rx-Tx Process/Peer Process/Peer
Disabled Tunnel Drop
