Nokia 7210 SAS-M Configuration Guide

Interface Configuration
7210 SAS M, T, X, R6, R12, Mxp, S, Sx Interface Configuration Guide Page 85
VPLS and Epipe
Services:
SDP to SAP
Sap Based Egress Scheduling:
All traffic (including VPLS Learnt
and Unlearnt)
9
: Based on
LAG SAP parameters: service-id,
lag_index, encap_value,
service_vlan, sap_index, , number of
active ports.
Port Based Egress Scheduling:
All traffic (VPLS Unlearnt)
9
: Based
on LAG SAP parameters: service-id,
lag_index, encap_value, service_vlan,
sap_index, , number of active ports.
All other Traffic(VPLS Learnt and
Epipe): Source and Destination
MAC(Outer MACs inside the
payload, just after the MPLS header)
Sap Based Egress Scheduling:
All traffic (including VPLS Learnt and
Unlearnt)
9
: Based on
LAG SAP parameters: service-id,
lag_index, encap_value,
service_vlan, sap_index, , number of
active ports.
Port Based Egress Scheduling:
All traffic (VPLS Unlearnt)
9
: Based on
LAG SAP parameters: service-id,
lag_index, encap_value, service_vlan,
sap_index, , number of active ports.
All other Traffic(VPLS Learnt and
Epipe): Source and Destination
MAC(Outer MACs inside the payload,
just after the MPLS header), Ingress
Port-Id
VPLS Service:
SDP to SDP
All traffic (Learnt): Source and
Destination MAC (Outer MACs
inside the payload, just after the
MPLS header
All traffic(Unlearnt): Hash-2 and
parameter under hash-2 used.
All traffic (Learnt and Unlearnt): Source
and Destination MAC (Outer MACs
inside the payload, just after the MPLS
header), Ingress Port-
Id.
MPLS – LSR All traffic: Source and Destination
MAC (Outer MACs of the ethernet
packet that encapsulates MPLS
packet)
All traffic: MPLS label stack (Three
labels deep), Ingress Port-Id, Source and
Destination IP (if MPLS labels are <= 3,
when IP header follows MPLS header),
Ingress Port-Id
Table 14: LAG Hashing mechanism for services configured on 7210 SAS-Mxp devices (Continued)
Services and Traffic
direction (For example-
SAP to SDP)
Packet fields used for Hashing for
different traffic types with hash-1
Packet fields used for Hashing for dif-
ferent traffic types with hash-2
