Nokia 7500b Service Manual

16
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
7500 RM-249 / RM250
Page (18) ISSUE 2
Service Manual Level 1&2
ASSEMBLY HINTS13.
1. Nokia 7500 Assembly Hints.
2. Insert the ANTENNA into the B-COVER ASSY starting with the
shown clip.
3. Secure the ANTENNA to the B-COVER by pressing it into place.
Avoid bending the spring contacts.
4. Ensure that the ANTENNA is tted correctly.
5. Insert the CAMERA MODULE paying attention to the correct
position.
6. Fit the CAMERA GASKET to the CAMERA MODULE.
