Nokia 8310 - E Nokia Corporation; General Specifications of Transceiver NHM-7

NHM–7
General Information
PAMS Technical Documentation
Page 7
Issue 2 01/2002
 Nokia Corporation
General Specifications of Transceiver NHM–7
Parameter Unit
Cellular system GSM900 and GSM1800
RX frequency band EGSM: 925 ... 935 MHz
GSM900 935 ... 960 MHz
GSM1800 1805 ... 1880 MHz
TX frequency band EGSM 880 ... 890 MHz
GSM900 890 ... 915 MHz
GSM1800 1710 ... 1785 MHz
Output power GSM900 * +5 ...+33 dBm / 3.2 mW ... 2 W
GSM1800 +0 ...+30 dBm / 1.0 mW ... 1 W
Duplex spacing GSM900 * 45 MHz GSM1800 95 MHz
Number of RF channels EGSM 50
GSM900 124
GSM1800 374
Channel spacing 200 kHz
Number of TX power levels GSM900 * 15 GSM1800 16
Sensitivity, static channel GSM900: –102 dBm
GSM1800: –102 dBm (norm. cond. only)
Frequency error, static channel < 0.1 ppm
RMS phase error < 5.0
o
Peak phase error < 20.0
o
*) applies also to EGSM
