Nokia Lumia 1020 Disassemble Guide

Nokia Lumia 1020 – Disassemble Guide
Page 2 of 7
hp://www.fixez.com/
First, use the SIM card ejection tool, or a paperclip, to
remove the SIM card tray from the Nokia smartphone.
1.
Next, remove the single T5 torx screw located in the
SIM card slot. Back the screw out, releasing the locking
bar for the display assembly (LCD & touch screen).
2.
On the locking bar side of the display, you will need to
pry the display assembly up using a plastic triangle
opening tool or spudger.
3.
Display Assembly (LCD & Touch Screen)

Nokia Lumia 1020 Specifications

General

Display	4.5 inches, AMOLED, 768 x 1280 pixels
RAM	2 GB
Operating System	Microsoft Windows Phone 8, upgradable to 8.1
Chipset	Qualcomm MSM8960 Snapdragon S4 Plus
CPU	Dual-core 1.5 GHz Krait
GPU	Adreno 225
Weight	158 g (5.57 oz)
Dimensions	130.4 x 71.4 x 10.4 mm (5.13 x 2.81 x 0.41 in)
Network	GSM / HSPA / LTE
Front Camera	1.2 MP, 720p
Internal Storage	32 GB
Battery	Li-Ion 2000 mAh, non-removable
Camera	41 MP, OIS, Xenon flash, LED flash
