Nokia Lumia 1020 Disassemble Guide

Nokia Lumia 1020 – Disassemble Guide
Page 3 of 7
hp://www.fixez.com/
When lifting the LCD and touch screen assembly with
the frame away from the smartphone, be sure to
release the two connectors (marked with orange
arrows) before completely removing it from the Nokia
Lumia 1020.
4.
Pry the front-facing camera assembly away from the
display assembly using your fine tip curved tweezers,
its secured with a small amount of adhesive. The use of
a heat gun or blow dryer is encouraged.
5.
Next, the locking bar is situated in the corner of the
smartphone and can be pried up and out of its location
with the fine tip curved tweezers. Carefully maneuver
it around the motherboard and lift it out of the Lumia
1020.
6.
Front-Facing Camera

Nokia Lumia 1020 Specifications

General

Display	4.5 inches, AMOLED, 768 x 1280 pixels
RAM	2 GB
Operating System	Microsoft Windows Phone 8, upgradable to 8.1
Chipset	Qualcomm MSM8960 Snapdragon S4 Plus
CPU	Dual-core 1.5 GHz Krait
GPU	Adreno 225
Weight	158 g (5.57 oz)
Dimensions	130.4 x 71.4 x 10.4 mm (5.13 x 2.81 x 0.41 in)
Network	GSM / HSPA / LTE
Front Camera	1.2 MP, 720p
Internal Storage	32 GB
Battery	Li-Ion 2000 mAh, non-removable
Camera	41 MP, OIS, Xenon flash, LED flash
