Nokia N-3100 User Manual

Nokia 3100 and Nokia 3120 User Guide 97 Copyright © 2004 Nokia
Technical information
27 Technical information
(3100 and 3120)
Feature Specification
Dimensions Width 1.68 in (42.8 mm)
Height 4.00 in (1.08 mm)
Depth 0.76 in (19.6 mm)
Weight 87.4 gm
with BL-5C Li-Ion Battery
Wireless networks GSM 900, 1800, and 1900 networks
Size (volume) 4.09 cu in (67 cu cm)
Frequency range (Tx) GSM 900: 880–915 MHz
GSM 1800: 1710–1785 MHz
GSM 1900: 1850–1910 MHz
Frequency range (Rx) GSM 900: 925–960 MHz
GSM 1800: 1805–1880 MHz
GSM 1900: 1930–1990 MHz
Tx output power 2W (GSM 900 max)
1W (GSM 1800/GSM 1900 max)
Battery voltage 3.7 Vdc
Number of channels GSM 900: 174
GSM 1800: 374
GSM 1900: 299
