Service Manual N95 RM-159/RM-245
Copyright © 2007 NOKIA Corporation. All rights reserved.
Approved 1.0
MGR
Page (58)
7. Shift the slider into the other position.
8. Unscrew these 2 screws in the order shown and discard them,
too.
9. Do not use them again.
10. Unlock these middle metal clips, hidden under the FRONT
COVER.
11. Turn the unit and release the second connector, too.
12. Peel up the protection lm.
