Nokia X2-01 Service Manual

Nokia X2-
01
RM-709/RM-717
Service Manual Level 1&2
3 Confidential | Copyright © 2010 Nokia | All rights reserved Version 2.0
CHANGE HISTORY
Status
Version No.
Date
Comments
Approved 1.0 20.10.2010 First approved version
Approved 2.0 25.11.2010 Added Assy hints
The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to
carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA
service suppliers, and the content of it is confidential. Please note that NOKIA provides also other
guidance documents (e.g. Service Bulletins) for service suppliers, follow these regularly and
comply with the given instructions.
While every endeavor has been made to ensure the accuracy of this document, some errors may
exist. If you find any errors or if you have further suggestions, please notify NOKIA using the
address below:
Nokia Care Academy
service.manuals@nokia.com
Please keep in mind also that this documentation is continuously being updated and modified,
so watch always out for the newest version.

Nokia X2-01 Specifications

General

Display Type	TFT, 256K colors
Display Size	2.4 inches
Resolution	320 x 240 pixels
RAM	64 MB
Expandable Storage	microSD, up to 16 GB
Main Camera	VGA
Battery Capacity	1020 mAh
Stand-by	Up to 480 h
Talk time	Up to 4 h 30 min
Operating System	Series 40
Dimensions	119.4 x 59.8 x 14.3 mm
Network Technology	GSM
2G bands	GSM 850 / 900 / 1800 / 1900
GPRS	Class 32
EDGE	Class 32
Announced	2010, November
Status	Discontinued
SIM	Mini-SIM
Keyboard	QWERTY
Alert types	Vibration, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	Yes
Phonebook	Yes, Photocall
Call records	Yes
Video	Yes
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Messaging	SMS, MMS, Email, IM
Browser	WAP 2.0/xHTML, HTML
Java	Yes, MIDP 2.1
Battery Type	Li-Ion
Weight	107.5 g
Games	Yes
Features	Predictive text input, Organizer
Colors	Red
