X-804
INSTRUCTIONS FOR USE
through the use of optional pads of different thicknesses available as standard or as
accessory/spare part.
1 ADJUSTING THE LINER FIT
To adjust the t, proceed as follows after removing the liner from the helmet (see pre-
vious instructions).
1.1 Deform the upper elastic cover on the outside of the liner and gently pull out its
standard-thickness inner expanded foam padding (Fig. 25).
1.2 Arrange the inner expanded foam padding with different thickness (see table be-
low) to increase or decrease its thickness, thus varying the localised pressure on
the head and consequently the t of the helmet.
THICKNESS FITTING
5 mm (optional) Large
8 mm Standard
8 mm + 5 mm (optional) Narrow
1.3 Slip the inner expanded foam padding into the liner by deforming the upper elastic
cover. Carefully lay the padding, checking that there are no wrinkles in the fabric
lining of the liner.
1.4 If deemed necessary, repeat the previous steps to vary the thickness of the ex-
panded foam pads of the rear area (Fig.26) and/or the left and right side areas
(Fig.27) of the liner.
1.5 Completely ret the liner in the helmet (see previous instructions).
1.6 Wear the helmet for a reasonable amount of time, correctly fastened, and check
that the t and perceived comfort is satisfactory for your head and that there is no
excessive pressure or discomfort. If not, adjust it again.
WARNING
After adjusting the position of the liner, put on and fasten the helmet to check the cor-
rect adjustment of the chin strap (see the attached label). Check also the correct helmet
t on your head in riding position setup, as well as its easy taking off - see “CHOICE
AND VERIFICATION OF THE HELMET” instructions above.
EYEWEAR ADAPTIVE
1 CREATING SPACE FOR GLASSES
1.1 Remove the left cheek pad from the helmet (see instructions above).
1.2 Remove the inner expanding foam cheek padding (see instructions above).
1.3 Remove the upper part of the pre-punched inner padding (Fig.28), then properly
reposition the remaining part of the padding in the cheek pad.
It is recommended that you keep the removed padding for any subsequent
reuse.
1.4 Assemble the inner expanding foam cheek padding (see instructions above).
1.5 Reassemble the full cheek pad on the helmet (see instructions above).
1.6 Follow these operations with the right cheek pad padding.
