2
contents
Explanation of Noralsy
®
Access Passes 3
General Door Controller Information 4
ECP 190 Door Controller schematic 5
ECP 290 Door Controller schematic 6
How to use the Telpro
™
programmer 7-8
Programming
Set-up on installation 9-10
Block loading of Access Passes 10
Deleting individual Access Passes 10-11
Validating individual Access Passes 11
Block deletion of Access Passes 11
Changing lock output time 11
Changing the Master Code 11
ECP290 Additional Features 12-13
Dual Security, Code + Access Pass 13
Fail Safe locking schematic 14
Automation/Volt Free schematic 14
General Locking schematic 15
Din Rail Mounting 15
Din Rail Power Supplies 16
Powering ECP Door Controllers using Din Rail PSU 17
Programming Keypad Codes 18-19
ECP190 / ECP290
DOOR CONTROLLERS
ECP190 / ECP290
DOOR CONTROLLERS
