ENGLISH (default), FRANCAIS,
DEUTSCH, ITALIANO, ESPAÑOL,
DANSK, NEDERLANDS, SUOMI,
NORSK, SVENSKA, PORTUGUES.
Set language of operation.
Any 6 numeric characters
(default = ‘000000’).
Set date DD/MM/YY or MM/DD/YY.
100Hz to 2500Hz (defaults, see ‘MODES
OF MEASUREMENT’ section).
Select mode then select frequency from list.
OTHER FREQUENCY allows a custom
value.
See ‘SERIAL PORT’ section.
FIRST PEAK SENSITIVITY =
LOW / MEDIUM / HIGH
(default = HIGH).
This is the amount by which the torque must
drop to register a first peak.
LOW must drop 10% of reading.
MEDIUM must drop 5% of reading.
HIGH must drop 2.5% of reading.
AUTO RESET HOLD TIME =
1 (default) / 2 / 3 / 4 seconds.
The time allowed for automatic reset in ‘Click
& Cam’ mode.
TRIGGER FROM =
0.5% to 99% of transducer capacity
(default = 1.8 %).
This is the point at which any memory mode
starts to work, all memory modes will
‘TRACK’ below this setting. This can help
overcome false results. Values entered
below 0.5% will act as 0.5%.
PEAK MEMORY RESET =
AUTO / MANUAL (default).
All Peak modes will reset the highest reading
automatically or manually.
All units (default = all enabled).
Turn off unwanted torque units.
All modes (default = all enabled).
0 to 99 minutes (default = 10).
The time before power down starts.
Set to ‘0’ to disable.
All settings and limit settings can be printed.
No password is needed.
TIP: When or is shown on screen, this means more menu items are available.
For more information see flow diagram on page 9.
3. Return to Measure
This option allows the user to view the measurement screen.
For ‘SMART’ transducers the measure screen is automatically entered.
For ‘NON-SMART’ transducers the option to store transducer details is available.
For more information see flow diagram on pages 7 & 8.
