DE441/EV441 PARTS LIST - PAGE 3
CABINET ASSEMBLY - FRONT VIEW - DE441/EV441
NO. PART # DESCRIPTION DE441 EV441
1 61632930 MOUNTING CLIP-RH/WHITE/EVAPORATOR DOOR X X
2 619041 SPRING HOLDER ASSY-RH/EVAP DOOR/SILVER SPRING X X
3 61630422 ICE CUBE TRAY-PLASTIC (ONE PER REFRIGERATOR) 1 1
4 61580830 HINGE BRACKET-RH TOP/LH BTM/BLACK X X
5 61578130 HINGE PIN-BLACK/MALE XX
NS 61580630 HINGE PIN-BLACK/TOP/BOTTOM HINGE/FEMALE (NOT SHOWN) X X
6 61578522 DOOR LATCH XX
7 618052 SHELF-WIRE/M IDDLE XX
8 618056 SHELF-WIRE/WHITE/FLIPPER X X
NS 618065 CAP-CLEAR/FOR FLIPPER SHELF (NOT SHOWN) X X
NS 61580222 RETAINER-WIRE SHELF (NOT SHOWN) X X
9 61580930 HINGE BRACKET-LH TOP/RH BTM/BLACK X X
10 61633030 MOUNTING CLIP-LH/WHITE/EVAPORATOR DOOR X X
11 619042 SPRING HOLDER ASSY-LH/EVAP DOOR/YELLOW SPRING X X
12 61622130 FRONT COVER-BLACK/REPLACEABLE BOTTOM TRIM X X
13 61686722 COVER PLATE-FRONT/BLACK X X
14 620377 THERMOSTAT XX
160206700 KNOB-THERMOSTAT XX
15 620502 COVER PLATE-THERMOSTAT X X
16 61772122 BOTTOM PAN-SUPPORT ASSY X X
17 61678338 EVAPORATOR DOOR ASSY X X
NS 61698030 DOOR GASKET-EVAPORATOR/GRAY (NOT SHOWN) X X
18 61693710 DRIP TRAY (NOT SHOWN) XX
NS 61579730 CAP-SNAP ON/BLACK/INSTALLATION HOLES (NOT SHOWN) X X
