N41/N51 SERIES PARTS LIST - PAGE 5
CABINET ASSEMBLY - REAR VIEW - N41/N51 SERIES
NO. PART # DESCRIPTION
N410
SERIES
N412
SERIES
N510
SERIES
N512
SERIES
1 623885 CONTROL PANEL/OPTICAL OVERLAY ASSY-EG2/TAUPE EG2 EG2
623886 CONTROL PANEL/OPTICAL OVERLAY ASSY-EG3/TAUPE EG3 EG3
627469 CONTROL PANEL/OPTICAL OVERLAY ASSY-EG2/BLACK EG2 EG2
627470 CONTROL PANEL/OPTICAL OVERLAY ASSY-EG3/BLACK EG3 EG3
2 622257 OPTICAL DISPLAY BOARD (EG2 - 9140558 & BELOW)(EG3 - 9159955 & BELOW) X X X X
628663 OPTICAL DISPLAY BOARD (EG2 - 9140559 & ABOVE)(EG3 - 9159956 & ABOVE) X X X X
3 622261 COVER-REAR/OPTICAL DISPLAY X X X X
4 61689122 CLIP-THERMISTER MOUNTING/FIN X X X X
5 621785 THERMISTER (EG2 - 9140558 & BELOW)(EG3 - 9159955 & BELOW) X X X X
628760 THERMISTER (EG2 - 9140559 & ABOVE)(EG3 - 9159956 & ABOVE) X X X X
6 621237 SPACER-CONDENSER/FOR COOLING UNIT X X X X
7 618950 WIRE MOUNT-ADHESIVE X X X X
8 61686823 FINS XXXX
9 619124 BRACE-CORNER/CABINET/RH X X X X
10 621462 NSC SYSTEM PACK-COOLING UNIT X X
621427 NSC SYSTEM PACK-COOLING UNIT X X
NS 61679022 BAFFLE DIFFUSER-SPIRAL FLAM E SPREADER X X X X
NS 61632010 WIRE-BAFFLE DIFFUSER/FORMED X X X X
11 61695022 CAP-HEAT DEFLECTOR X X X X
12 61562522 HEATER-AC/200W/110VAC X X X X
13 620884 HEATER-DC/EG3 EG3 EG3
14 61712637 COVER ASSY-BURNER BOX X X X X
NS 61695322 BASE-BURNER BOX (NOT SHOWN) X X X X
15 622546 DRIP CUP-REAR/PLASTIC X X X X
16 621955 KIT-BURNER/ORIFICE ADAPTER ASSY X X X X
17 621173 PRESSURE TAP/SWIVEL CONNECTOR ASSY OM OM
NS 621086 PRESSURE TAP TEE ASSY-WITH PLUG (PARTS OF 621173) OM OM
NS 61445322 PLUG-1/8"/FOR PRESSURE TAP OM OM
NS 621079 CONNECTOR-SWIVEL NUT OM OM
NS 61692222 ELECTRODE-SPARK/SENSE X X X X
18 621448 WIRE-WHITE/9"/GAS VALVE (EG2 - 9140558 & BELOW)(EG3 - 9159955 & BELOW) NOTE NOTE NOTE NOTE
19 628741 GAS VALVE (EG2 - 9140559 & ABOVE)(EG3 - 9159956 & ABOVE) X X X X
628995 GAS VALVE/BRACKET ASSY (EG2 - 9140558 & BELOW)(EG3 - 9159955 & BELOW) X X X X
20 624685 BRACKET-MOUNTING/GAS VALVE (EG2-9140558 & BELOW)(EG3-9159955 & BELO
W
XXXX
628994 BRACKET-MOUNTING/GAS VALVE (EG2-9140559 & ABOVE)(EG3-9159956 & ABOV
E
XXXX
21 61554422 CORD-AC POWER/BLACK X X X X
22 626672 BURNER TUBE XXXX
NS 624684 BURNER TUBE (M ODELS WITH PRESSURE TAP) OM
23 618185 COVER-POWER SUPPLY (EG2 - 9140558 & BELOW)(EG3 - 9159955 & BELOW) X X X X
628677 COVER-POWER SUPPLY (EG2 - 9140559 & ABOVE) X X X X
628678 COVER-POWER SUPPLY (EG3 - 9159956 & ABOVE) X X X X
24 632168001 KIT-POWER BOARD (EG2 - 9140558 & BELOW) EG2 EG2 EG2 EG2
621268001 KIT-POWER BOARD (EG3 - 9159955 & BELOW) EG3 EG3 EG3 EG3
628661 POWER BOARD (EG2 - 9140559 & ABOVE)(EG3 - 9159956 & ABOVE) X X X X
NS 628669 DC BOARD (EG3 - 9159956 & ABOVE) EG3 EG3 EG3 EG3
25 619119 BRACE-CORNER/CABINET/LH X X X X
26618186BASE-POWER BOARD (EG2 - 9140558 & BELOW)(EG3 - 9159955 & BELOW) XXXX
628674BASE-POWER BOARD (EG2 - 9140559 & ABOVE) XXXX
628675BASE-POWER BOARD (EG3 - 9159956 & ABOVE) XXXX
NS621780WIRING HARNESS (EG2 - 9140558 & BELOW)(EG3 - 9159955 & BELOW)) XXXX
NS628761WIRING HARNESS (EG2 - 9140559 & ABOVE)(EG3 - 9159956 & ABOVE) XXXX
NS 628763 WIRE-INPUT/RED (DC/DEFROST BOARD TO POWER BOARD ( 9159956 & ABOVE) EG3 EG3 EG3 EG3
NS 628764 WIRE-INPUT/BLACK (DC/DEFROST BOARD TO POWER BOARD ( 9159956 & ABOVE) EG3 EG3 EG3 EG3
NS = NOT SHOWN OM = OLDER MODELS WITH PRESSURE TAP
NOTE: 621448 IS A PART OF THE WIRING HARNESS ON (EG2 - 9140558 & BELOW)(EG3 - 9159955 & BELOW)
