Owner’s Manual 16
Remove the Refrigerator
Your dealer or Norcold authorized service center must do this procedure.
The rear of the refrigerator has sharp edges and corners. To prevent cuts or abrasions when working on the
refrigerator, be careful and wear cut resistant gloves.
1. Close the valve at the propane gas tank(s).
To avoid possible propane gas leaks, always use two wrenches to loosen and tighten the gas supply line
connections.
2. Remove the black AC power cord and the white ice maker AC power cord (N10LXIM and NA10LXIM models only) from the
receptacle.
3. Remove the DC wiring from the refrigerator:
- Put a mark on the DC wires so you can put them back in the correct location.
- Remove the DC fuse or remove the DC wiring from the battery or the converter.
- Remove the DC wires from the refrigerator.
4. Open the lower intake vent and remove the gas supply line from the combination gas valve of the refrigerator.
5. Remove the garden hose adapter from the water solenoid valve (N10LXIM and NA10LXIM models only).
6. Remove the screws from the mounting ange at the rear of the refrigerator.
7. Remove the upper and lower trim pieces from the mounting anges of the refrigerator.
8. Remove the screws from the upper and lower mounting anges on the front of the refrigerator.
9. Remove the refrigerator from the opening.
!
!
- Clean the openings of the burner tube with compressed air pressure only (See Art
02671)
- Assemble the gas train assembly back to the cooling unit and tighten the two
screws removed.
- Assemble the gas supply to the gas train assembly and tighten using two
wrenches.
- Open the valve at the supply gas tank(s) and turn on the refrigerator choosing gas
as the power source.
- Check all connections for gas leaks using leak test solution.
- Replace lower intake vent.
Air
Air
Air
Air
