nord C2 User Manual

&EWW4IHEP
To play the Nord C2 Combo Organ’s dedicated bass registers, connect
the MIDI Out from your external controller (preferably a bass pedal-
board) to the Bass Pedal connector. The bass registers will respond to
all MIDI note messages received regardless of their MIDI channel.
%YHMSGSRRIGXMSRW
1SRMXSV-R
Use this to connect and monitor a signal from an mp3 or a CD player
at the Nord C2's headphone output. This allows you to e.g. rehearse
with the C2 to pre-recorded music.
Signals connected to this input will not be processed with the M
Nord C2's effects or appear at the left and right output jacks.
1EMRWXIVISSYXTYX0IJX6MKLX
The left and right line level outputs from the Nord C2 are unbalanced.
Use the ¼" connectors to connect the Nord C2 to an amplifier or
recording equipment.
General guide on audio connections:
t.BLFBMMUIFDPOOFDUJPOTCFGPSFZPVUVSOPOUIFQPXFSUPZPVSBNQMJmFS
t5VSOPOUIFQPXFSUPZPVSBNQMJmFSMBTU
t5VSOPGGUIFQPXFSUPZPVSBNQMJmFSmSTU
,IEHTLSRISYXTYX
This is where you connect a ¼" stereo connector from a pair of head-
phones.
Playing at a high volume level can result in hearing impairments E
such as permanent hearing loss.
6SXEV]7TIEOIV
The rotary speaker high level outputs consist of a ¼" and a 11-pin
Leslie™ standard connector. The high level out are 14V RMS high level,
unbalanced, and are only intended to be used, directly connected to
a rotary speaker cabinet with built in amplifier. Any other form of use
might result in damaged equipment.
It is possible to route the tonewheel organ to the High Level and 11-pin
outputs and the other organs to the main outputs. Other combinations
are also possible. Read more about this on page 17.
 '322)'8-327 ` 
