Nordic RENDEZVOUS - Page 8

8
| NORDIC HOT TUBS | OWNER’S MANUAL
POWER INSTALLATION INSTRUCTIONS CONTINUED
8"
8"
82"
34"
A good location
for the wire to
enter through
the bottom.
Access Panel
17.5" radius
BELLA D’AMOUR
ESCAPE
RETREAT
8-10"
84"
28-30"
68"
72"
10" radius
20" radius
20" radius
A good location
for the wire to
enter through
the bottom.
Access Panel
10" radius
81.5"
79"
12-24"
8-10"
24-28"
4-6"
A good location
for the wire to
enter through
the bottom is
4-6" from the left
side and 24-28"
from the front
A good location
for the wire to
enter through
the bottom is
8-10" from the
front and 12-24"
from the right
side of the tub
Access Panel
10" radius
80"
70"
4-6"
Access Panel
12-16"
A good location for the wire to
enter through the bottom is
4-6" from the left side and
12-16" from the front
