Nordyne B6VM Series User Manual

22
Table 12. Control Board Operation
CONTROL SIGNAL & MODE OPERATION TOTAL KW BOARD ACTION
W1 ONLY
EHEAT
ON
5 KW
Stage 1 Heat on instantly
Heat blower on after 3 second delay
10 KW
Stage 1 Heat on instantly
Heat blower on after 3 second delay
15 KW
Stage 1 Heat on instantly
Heat blower on after 3 second delay
Stage 2 Heat on after 5 second delay
20 KW
Stage 1 Heat on instantly
Heat blower on after 3 second delay
Stage 2 Heat on after 5 second delay
Stage 3 Heat on after 10 second delay
25 KW
Stage 1 Heat on instantly
Heat blower on after 3 second delay
Stage 2 Heat on after 5 second delay
Stage 3 Heat on after 10 second delay
30 KW
Stage 1Heat on instantly
Heat blower on after 3 second delay
Stage 2 Heat on after 5 second delay
Stage 3 Heat on after 10 second delay
Stage 4 Heat on after 15 second delay
OFF —
Heat stages off instantly
Blower off after 15 second delay
Table 11. B6(E,V)M MCA & MOP Data
B6(E,V)M MINIMUM CIRCUIT AMPACITY & MAXIMUM OVERCURRENT PROTECTION
CABINET CAPACITY
HEAT KIT
MODEL
NUMBER
H6HK-
240 VAC, 50 & 60 HZ, SINGLE PHASE 208 VAC, 50 & 60 HZ, SINGLE PHASE
MCA MOP MCA MOP
CIRCUIT
A
CIRCUIT
B
CIRCUIT
C
SINGLE
CIRCUIT CIRCUIT
A
CIRCUIT
B
CIRCUIT
C
SINGLE
CIRCUIT CIRCUIT
A
CIRCUIT
B
CIRCUIT
C
SINGLE
CIRCUIT CIRCUIT
A
CIRCUIT
B
CIRCUIT
C
SINGLE
CIRCUIT
A
24/30
NONE 4.5 - - 4.5 15 - - 15 4.8 - - 4.8 15 - - 15
005H-XX 29.5 - - 29.5 30 - - 30 26.4 - - 26.4 30 - - 30
008H-XX 44.1 - - 44.1 45 - - 45 39.1 - - 39.1 40 - - 40
010H-XX 54.5 - - 54.5 60 - - 60 48.1 - - 48.1 50 - - 50
015H-XX 54.5 25.0 - 79.5 60 30 - 80 48.1 21.7 - 69.8 50 25 - 70
009Q-XX - - - 31.6 - - - 35 - - - 28.2 - - - 30
015Q-XX - - - 47.8 - - - 50 - - - 42.3 - - - 45
B
24/30/
36/42
NONE 4.5 - - 4.5 15 - - 15 4.8 - - 4.8 15 - - 15
005H-XX 29.5 - - 29.5 30 - - 30 26.4 - - 26.4 30 - - 30
008H-XX 44.1 - - 44.1 45 - - 45 39.1 - - 39.1 40 - - 40
010H-XX 54.5 - - 54.5 60 - - 60 48.1 - - 48.1 50 - - 50
015H-XX 54.5 25.0 - 79.5 60 30 - 80 48.1 21.7 - 69.8 50 25 - 70
020H-XX 54.5 50.0 - 104.5 60 60 - 110 48.1 43.3 - 91.4 50 45 - 100
009Q-XX - - - 31.6 - - - 35 - - - 28.2 - - - 30
015Q-XX - - - 47.8 - - - 50 - - - 42.3 - - - 45
C
48/60
NONE 6.3 - - 6.3 15 - - 15 6.8 - - 6.8 15 - - 15
005H-XX 31.3 - - 31.3 35 - - 35 28.4 - - 28.4 30 - - 30
008H-XX 45.8 - - 45.8 50 - - 50 41.1 - - 41.1 45 - - 45
010H-XX 56.3 - - 56.3 60 - - 60 50.1 - - 50.1 60 - - 60
015H-XX 56.3 25.0 - 81.3 60 30 - 90 50.1 21.7 - 71.8 60 25 - 80
020H-XX 56.3 50.0 - 106.3 60 60 -
110 50.1 43.3 - 93.4 60 45 - 100
024H-XX 56.3 50.0 25.0 131.3 60 60 30 150 50.1 43.3 21.7 115.1 60 45 25 125
029H-XX 56.3 50.0 50.0 156.3 60 60 60 175 50.1 43.3 43.3 136.8 60 45 45 150
009Q-XX - - - 33.3 - - - 35 - - - 30.2 - - - 35
015Q-XX - - - 49.6 - - - 50 - - - 44.3 - - - 45
