2. COIL SPECIFICATIONS
(1) Refer to sales specification sheets for Listed/
Certified combinations of equipment and re-
quired accessories.
(2) Refer to the current ARI Directory for certified
ratings of split systems.
(3) Orifice size is for 10 SEER systems. Additional
orifices may be supplied with the coil.
(4) Allows application of larger coil cases to
smaller furnace cabinet.
(5) This coil is for 4 ton 12 SEER match.
(6) An X in the model description designates
factory installed TXV.
Coil Model
(1)
C3BA-
024C-A
C3BH-
024C-A
C3BA-
030C-A
C3BH-
030C-A
C3BA-
036C-A
C3BH-
036C-A
C3BA-
043C-A
C3BA-
030C-B
C3BA-
036C-B
C3BH-
036C-B
C3BA-
042C-B
C3BH-
042C-B
C3BA-
048C-B
C3BH-
048C-B
(5)
C3BA-
050C-B
C3BA-
048C-C
C3BA-
060C-C
C3BH-
060C-C
Nominal Capacity BTUH
(2)
24,000 24,000 30,000 30,000 36,000 36,000 43,000 30,000 36,000 36,000 42,000 42,000 48,000 48,000 48,000 48,000 60,000 60,000
Nominal Airflow 900 900 1100 1100 1200 1200 1400 1100 1350 1350 1500 1500 1500 1500 1500 1500 1800 1800
Installed Orifice Size
(3)
0.060 0.060 0.063 0.063 0.067 0.067 0.080 0.063 0.067 0.067 0.075 0.075 0.080 0.080 0.080 0.080 0.093 0.093
Width (in.) W 14 1/4 14 1/4 14 1/4 14 1/4 14 1/4 14 1/4 14 1/4 19 3/4 19 3/4 19 3/4 19 3/4 19 3/4 19 3/4 19 3/4 19 3/4 22 1/2 22 1/2 22 1/2
Height (in.) H 202020262026262020262026202626202626
Top F 12 7/8 12 7/8 12 7/8 12 7/8 12 7/8 12 7/8 12 7/8 18 3/8 18 3/8 18 3/8 18 3/8 18 3/8 18 3/8 18 3/8 18 3/8 21 1/8 21 1/8 21 1/8
Connections (in.)
Liquid Line 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Suction Line 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 7/8 3/4 7/8 7/8
Horizontal Drain Kit 914633 - 917492 - 917492 - 914634 917492 917492 - 917492 - 917492 - 914634 914633 914634 -
Coil Case Adapter
(4)
- - - - - - - 913963 913963 913963 913963 913963 913963 913963 913963 913964 913964 913964
R - 22 Units
Coil Model
(1) (6)
C4BA-X24C
B
C4BH-X24C
B
C4BA-X36C
B
C4BH-X36C
B
C4BA-X48C
C
C4BH-X48C
C
C4BA-X60C
C
C4BH-X60C
C
Nominal Capacity BTUH (2)
24,000 24,000 36,000 36,000 48,000 48,000 60,000 60,000
Nominal Airflow 900 900 1350 1350 1500 1500 1800 1800
Metering Device TXV TXV TXV TXV TXV TXV TXV TXV
Width (in.) W 19 3/4 19 3/4 19 3/4 19 3/4 22 1/2 22 1/2 22 1/2 22 1/2
Height (in.) H 20 26 26 26 29 29 29 29
Top F 18 3/8 18 3/8 18 3/8 18 3/8 21 1/8 21 1/8 21 1/8 21 1/8
Connections (in.)
Liquid Line 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Suction Line 3/4 3/4 7/8 7/8 7/8 7/8 7/8 7/8
Horizontal Drain Kit 917492 - 914634 - 917188 - 917188 -
Coil Case Adapter (4) 913963 913963 913963 913963 913964 913964 913964 913964
R - 410A Units
